EAN:
SKU: PSTY05O Built-in Tire Pressure Sensor Vehicle Tire Pressure Sensor USB Tire Pressure Monitoring Sensor Bluetooth Communication 4.0/5.0 Monitoring Sensor TPMS Battery 433.92mhz Component 4-Wheel (4pc) Real-time Monitoring Tire Pressure Too High Tire Pressure Too Low Detection Data iOS/Android/iPad Independent APP
product description
Installation type: built-in tire pressure sensor
Valve core assembly: 4pcs
Material: ABS+
Color: Black
Sensor parameters:
Pressure range: 0-8 bar / 0-116 psi
Sensing frequency: 433.92Mhz
Main control chip: DA14531
Pressure accuracy: ±0.1 bar / ±1.5 psi
Default low pressure alarm value: 1.8 bar
Default high pressure alarm value: 3.0 bar
Maximum pressure: 0.1-4.2 bars
Bluetooth communication: 4.0/5.0
Input voltage: DC-5V
Response time: ≤5s
Display mode: APP
MAX fetal pressure detection range: 100-1300kPa
Pressure detection accuracy: 10kPa
Fetal temperature detection accuracy: 3℃
Working temperature: -30℃ +70℃
Storage temperature: -30℃ +70℃
Battery: CR1632 button battery (can be removed and replaced by yourself)
Life: 1-2 years typical value
Valve core: pure copper
Water resistance: IP67
Receiver parameters:
Power supply: Connect to Android in-car DVD navigation
Pressure unit: bar / psi
Temperature unit: ℃ / ℉
Product certification: CE FCC ROHS UKCA
Product features
1. Practicality: APP compatible with Android DVD navigation. Voice prompt when tire pressure is abnormal. Pure copper valve core can withstand greater pressure impact.
2. Easy to use: plug and play, easy to install. It also displays the pressure or temperature of four tires at the same time. You can also choose to display a spare tire software package.
3. Adjustable use: Adjustable tire pressure alarm value. Tire matching mode can easily re-match the new sensor. Tire replacement mode can easily replace any two tires.
4. Low / high pressure: high temperature alarm. Slow and fast tire puncture warning.
5. Optional tire pressure units: bar, psi, kpa, kg.
Powerful TPMS:
1. Tire pressure monitoring system (TPMS) can monitor tire pressure/temperature status in real time.
It will transmit real-time voice alarms and flashing alarms to alert drivers to the comfort and safety of their vehicles.
2. Display tire pressure and temperature simultaneously.
3. Leakage warning, low pressure warning and high pressure warning.
4. High temperature warning, low power warning, no signal warning.
5. The system is widely used in vehicles with four tires, such as commercial vehicles, jeeps, off-road vehicles, minibuses and cars.
6. We offer four sensors suitable for use in rainy weather. In addition, they have high sensitivity and good accuracy in measuring pressure and temperature.
keyword
Motorcycle tire pressure sensors Bluetooth tire pressure monitors automotive tire pressure monitors tire abnormality alarms external tire pressure sensors internal tire pressure sensors air compressors and inflators fenders and splash guards tire maintenance tire covers tire pressure gauges tire pressure monitoring systems monitoring tire pressure sensors valve stems and valve covers tire repair kits tire repair tools wheel hub bearings wheel alignment and balancing wheel accessories tire accessories tire and wheel repair automotive tire pressure digital instruments automotive public bus truck tractor tractor bicycle motorcycle tire pressure testing tools airbag scanners and simulators battery testers decoders and scanning tools electrical testers and test leads emission analyzers fuel pressure testers gas analyzers ignition testers laboratory oscilloscopes mechanical testers multimeters and analyzers pressure and vacuum testers software thermometers timing lights
Packaging information
Product size: mm
Packaging size: 18X12X7 cm
Net quantity of goods: 450g
Gross quantity of commodity: 500g
